RA-6000 Integrated Amplifier

The Diamond Series RA-6000 Integrated Amplifier celebrates Rotel’s 60-Years of Japanese heritage. The RA-6000 supports a wide array of modern and legacy analog and digital sources delivering 350 watts of Class AB power into 4 ohms with exceptional acoustic detail and controlled rich, deep bass energy.

Digital inputs support 24-bit/192kHz audio streams. The asynchronous PC-USB input supports up to 32-bit/384kHz audio, decodes and renders MQA, and is fully certified Roon Tested.  A Moving Magnet Phono stage is also included for vinyl fans.

Front panel controls, back-lit IR remote and 2-line display ensure intuitive operation.

Ethernet, RS232,12V trigger and external remote input simplify integration with control systems.

The RA-6000 is available in both black and silver colors.

Features

• Certified Roon Tested
• Supports MQA and MQA Studio
• x 350 Watts of robust
• Class AB power, 4 Ohms
• Wireless aptX™ HD and
• AAC Bluetooth
• Texas Instruments
• Premium 32-bit/384kHz
• Digital to Analog Converter

Description & Specifications

• Class AB amplification: 200 watts x 2 channels @ 8 ohms and 350 Watts x 2 channels @ 4ohms.
• Supports MQA & MQA Studio and is certified Roon Tested.
• Texas Instruments premium 32bit/384kHz DAC.
• 3 Coaxial and 3 Optical digital inputs.
• 3 Analog RCA inputs.
• MM phono stage input.
• Asynchronous PC-USB input supporting MQA and 32-bit / 384 kHz audio.
• Bluetooth with aptX HD and AAC. XLR Balanced input.
• In-house Toroidal Power Supply and high efficiency, low ESR slit foil smoothing capacitors.
• Front panel controls, a back-lit IR remote control and 2-line display provide intuitive operation of the unit.
• Ethernet, RS-232, 12V triggers and external remote input ensure seamless integrated with control systems.

SpecificationsMaximum Power Output350 watts/ch (4 ohms)Continuous Power Output200 watts/ch (8 ohms)Total Harmonic Distortion< 0.0075%Intermodulation Distortion (60 Hz : 7kHz, 4:1)< 0.03%Frequency Response - Phono Input20 Hz - 20k Hz, 0 ± 0.5 dBFrequency Response - Line Level Inputs10 Hz - 100k Hz, 0 ± 0.5 dBDamping Factor (20 Hz - 20 kHz, 8 ohms)600Input Sensitivity / Impedance - Phono Input (MM)5.2 mV / 47k ohmsInput Sensitivity / Impedance - Line Level Inputs (RCA)340 mV / 5.6k ohmsInput Sensitivity / Impedance - Line Level Inputs (XLR)540 mV / 100k ohmsInput Overload - Phono Input (MM)52 mVInput Overload - Line Level Inputs (RCA)3.5 VInput Overload - Line Level Inputs (XLR)4.5 VPreamplifier Output / Impedance1.9 V / 100 ohmsSignal to Noise Ratio (IHF A-weighted) - Phono Input (MM)80 dBSignal to Noise Ratio (IHF A-weighted) - Line Level Inputs103 dBDigital to Analog ConvertersTexas InstrumentsFrequency Response10 Hz - 90k Hz (0 ± 2 dB, Max)Signal to Noise Ratio102 dBInput Sensitivity/Impedance0 dBfs / 75 ohmsPreamplifier Output Level1.43 V (at -20 dB)Coaxial/Optical Digital SignalsSPDIF LPCM (up to 24-bit / 192k Hz)PC-USBUSB Audio Class 2.0 (up to 32-bit / 384k Hz )* *Driver installation required Support MQA and MQA Studio (up to 24-bit / 384k Hz ) Roon TestedPower Requirements - USA120 V, 60 HzPower Requirements - EC230 V, 50 HzPower Consumption500 wattsStandby Power Consumption - Normal< 0.5 wattsStandby Power Consumption - Network Standby< 2 wattsBTU (4 ohms, 1/8th power)1239 BTU/hDimensions (W x H x D)431 x 144 x 425 mmWeight (net)18.81 kg, 41.47 lbs.FinishSilver and Black
